ROLLBEND
ROLLBEND OHP-Series Hydraulic Horizontal Press Machine can easily perform bending and shaping for standard or special molds such as pipes, profiles and plates.
• Ergonomic Tool Clamping Table
• Easy Mold Change
• Hydraulic Speed and Pressure Adjustment
• Easily Adjustable Side support
• Induction Hardened Support Pins
• Mobile control panel
• Control Panel with Digital Readout
• NC Control
| MODEL | OHP-10 | OHP-20 | OHP-40 | OHP-60 | ||||||||
| Max Pressure At 200 Bars | Ton | 10 | 20 | 40 | 60 | |||||||
| Bending Capacity Flat Material | mm | 150X6 | 200X10 | 250X16 | 300X16 | |||||||
| Max Stroke | mm | 200 | 200 | 300 | 300 | |||||||
| Height Of Toolings | mm | 150 | 200 | 250 | 300 | |||||||
| Working Speed | mm/sec | 10 | 10 | 10 | 10 | |||||||
| Motor Power | kw | 1.1 | 2.2 | 4 | 5.5 | |||||||
| Net Weight | kg | 410 | 650 | 1210 | 1550 | |||||||
| Size Of The Table (LxW) | mm | 500X900X1150 | 600X1100X1220 | 650X1250X1300 | 750X1450X1360 | |||||||
